Digital Disinfection Unit ZA-208D
Fifth generation balanced sliding compensation chair frame design
-German KUKA machine manual automatic assembly (accuracy up to +0.08mm)
-The highest position of the Patient chair from the ground: ≥700mm
The lowest position of the Patient chair from the ground: ≤500mm.
-It only takes 9 seconds for the backrest to reach the working position
-ziann dental chari is equipped with comfortable neck and waist pillow, which is combined with strong support for the patient’s curve position, so that the spine is more comfortable.
-The design of the compensation chair makes the patient’s whole body blood circulation flow more smoothly, lying down for a long time is not tired, relaxed and comfortable.
NAPA enviromental leather cushion
-Thickness 1.2mm
-Good rebound resilience
-Wear-resistant,breathable an aging resistant
-Ergonomics design
Digital Disinfection Unit ZA-208D with Movable side box :
-100% pure ASA material Adopt injection molding process, It can be sealed, dust-proof, pollution-proof, easy to clean and keep clean 45 degree movable side box, opposite door is designed for easy maintenance
Detachable and Movable Spittoon:
-90 degree rotary glass ( ceramic opitonal ) spittoon
-Easy for cleaning
-deepenning the design to avoid splashing
Narrow type back of a chair:
-Backrest filled with slow rebound memory sponge, thickness Moderate, lying on your back with the comfort of being wrapped, Give patients a relaxed and safe experience.
-The leather cushion on the back is tightly woven with natural protein It’s woven. It’s a whole leather pad.
-Special Comfortable hand feel, can effectively reduce the patient’s back friction with the seat.
Adjustable Comfort Headrest:
-The adjustable curved headrest is more comfortable than the traditional flat headrest, it’s prevents the head from shaking and can be adjusted from multiple angles.
LED Operating Light
-Philips LED light source, Illumination for Operating Light: Low light > 15000Ix < Bright light, infrared sensor switch or touch switch to control stepless dimming. It’s with manual and sensor integration, flexible and agile movement, and easy to locate the required angle of lighting.
Digital Disinfection Unit ZA-208D with Instrument Tray:
-Cast aluminum tool tray
-More buttons on the control panel, more functions for direct use.LCD control panel, upgraded to digital dental chair, so that doctors more intuitive control.
-Large size instrument tray
-Accommodate more instruments and tools
-Suitable extension length hose rail design
-Overall cast aluminum, no rust, high hardness
Four hands operation assistant tray:
-With multi-functional control panel, it is convenient for assistant to use the common functions of dental chair and assist dentists to improve work efficiency.
Technical Parameters
| Illumination for Operating Light: | Low light > 15000Ix < Bright light |
| Illumination of the Film Viewer: | ≥2000Ix |
| Color temperature of the Film Viewer | ≥6500K |
| Starting force of the foot switch: | 10 N >starting force <50 N |
| Noise： | <70 dB（A） |
| Wastewater discharge： | >4 L/min |
| Working load of Patient： | 150 kg |
| Load weight of the Instrument Tray: | 5Kg |
| Load weight of Assistant frame : | 3Kg |
| Water Tank: | Capacity800ml&1200ml, pressure 0.25MPa |
| The highest position of the Patient chair from the ground: | ≥700mm |
| The lowest position of the Patient chair from the ground: | ≤500mm |
| Backrest movement range: | 105°- 170° |
| Head rack extension range: | 120mm |
| The biggest backward angle of the seat cushion: | ≤12° |
| Temperature of the constant temperature water heater: | (40±5)℃ |
| Work space: | length≥3000mm/width≥3000mm/height≥2500mm |
